Light up your project with LEDs. This pack includes four pairs of matched LEDs.

Rectangular high 2x5mm red LEDs (2)

Emitted color: Red

Intensity: 400mcd

Wavelength: 660nm

Type (size): 2.0x4.95mm

Lens color: Clear

Viewing angle: 80°

Forward current (IF): 30mA

Forward voltage (typical): 2.0V

Forward voltage (max.): 2.4V

RoHS compliant

Rectangular high 2x5mm green LEDs (2)

Emitted color: Green

Intensity: 200mcd

Wavelength: 660nm

Type (size): 2.0x4.95mm

Lens color: Clear

Viewing angle: 80ТА

Forward current (IF): 30mA

Forward voltage (typical): 2.0V

Forward voltage (max.): 2.4V

RoHS compliant

Rectangular high 2x5mm yellow LEDs (2)

Emitted color: Yellow

Intensity: 400mcd

Wavelength: 660nm

Type (size): 2.0x4.95mm

Lens color: Clear

Viewing angle: 80ТА

Forward current (IF): 30mA

Forward voltage (typical): 2.0V

Forward voltage (max.): 2.4V

RoHS compliant

Round 5mm bi-color LEDs (2)

Emitted color: Red/green

Intensity: 50; 32mcd

Wavelength (red): 635nm

Wavelength (green): 565nm

Type (size): T-1 5mm

Lens color: Clear

Power dissipation: 100mW

Continuous forward current: 25mA

Reverse current: 10uA (0.05V)

Reverse voltage: 5V

Forward voltage (red): 2.0V

Forward voltage (green): 2.0V

Viewing angle: 100°

RoHS compliant
